AN/PVS-31D (F5032) - White Phosphor - 2400 FOM with G24 Mount

• Gen III 2400+ FOM Minimum White Phosphor Tubes (Auto-Gated)
• Industry-leading, close-focus technology
• Articulating housing design
• Vertical viewing ability
• Adjustable diopter lenses
• Integrated IR illuminator
• Adjustable Gain Control
• Submersible up to 20 meters

Designed with an emphasis on special operations mission success, the AN/PVS-31D (F5032) night vision binocular delivers a tactical advantage in low-light and no-light combat scenarios. Engineered with close-focus technology, and an integrated IR illuminator. The AN/PVS-31D (F5032) provides improved operational performance and situational awareness

Clear, close focus, superior performance tactical NVG - Users can maintain their cover while performing critical, up-close tasks—as near as nine inches—with more clarity than standard night vision goggles. An automatic vertical viewing system recognizes when the binocular is in use and prevents shut-off from activating when a user tilts their head to look up. An auto shut-off functions only when the goggles are in the stowed position.

Key Benefits:

• Adjustable diopter lenses to minimize eye strain
• Single, self-contained AA battery with an alert when running low
• Manual Gain Control Standard.

SPECIFICATIONS

OPTICAL
Magnification: 1X
System Distortion: <3%
Field of View: 40° ± 2°
System Focus: 25 cm to Infinity
Resolution: ≥ 1.3 cyc/mrad
Collimation: 1° convergence | 0.3° dipvergence/divergence
Diopter Adjustment Lenses**: +2 to -2.5

PHYSICAL
Weight*: Less than 500 gm
Environmental: Complies with MIL-STD-810

ELECTRICAL
Battery: One AA size battery
Battery Life @23° C without IR on:
> 24 hours with AA Lithium
> 15 hours with AA Alkaline

Integrated IR Illuminator: Yes
Automatic High Light Cut-off System to Protect Image Intensifier Tube: Yes
Internal LED Indicators for IR ON and Low Battery: Yes

MECHANICAL ADJUSTMENTS
Interpupilary Adjustment: 52 to 75 mm

Flip-Up Function: Binocular is automatically switched off when in the flip-up position
Independent Monocular Flip-out Stow: Yes

*Fixed diopter lens configuration without variable gain control
**Fixed diopter lens configuration
