Steiner DBAL-A4

Steiner DBAL-A4

Be the first to review this product

DUAL BEAM AIMING LASER - ADVANCED⁴

ETA TO SHIP OUT GREEN VIS MODELS IS LATE NOVEMBER/DECEMBER

Availability:Out of stock

Description

New advanced DBAL-A4 with four functionalities: visible green laser, IR Laser, IR Illuminator, and white light. High/low modes. Civilian and restricted models available.

Integrated push-button switch and remote cable pressure-pad switch activation – tap and release for momentary activation; tap twice for 5-minute continuous on

Attaches to any Picatinny rail using the patented, self-adjusting Quick Release HT Mount

Dual remote activation ports for visible override.

OPTIONS:

9014-black case, green laser - new in packaging.
9016- desert sand case, green laser - new in packaging.
9032-black case, red laser - new in packaging.
9033-desert sand case, red laser - new in packaging.

PRODUCT FEATURES:

Spot (Narrow Field of View) and Flood (Wide Field of View) Illumination
Fully adjustable windage and elevation
Integrated fire button and remote cable pressure pad switch activation. Tap and release for momentary action; tap twice for 5-minute continuous on
Attaches to any Picatinny rail using secure quick disconnect (QD) mount
Two remote cable ports at rear of unit for paddle switch activation and visible laser/white light override capabilities
500 lumen tactical white light

Specifications:

Wavelength - Visible Red Laser	525 nm +/-3%
Wavelength - Visible Green Laser	525 nm +/-3%
Wavelength - IR Laser	850 nm +/-3%
Wavelength - IR Illuminator	850 nm +/-3%
Wavelength - White Light	500 lumens
Beam Divergence - Visible Red or Green Laser	<0.5 mRads
Beam Divergence - IR Laser	<0.5 mRads
Beam Divergence - IR Illuminator	4° / 90°
Range/Visibility (Night/Day)* - Visible Green Laser	>2000 m / >50 m
Range/Visibility (Night/Day)* - Visible Red Laser	100 m
Range/Visibility (Night/Day)* - IR Laser	1400 m
Range/Visibility (Night/Day)* - IR Illuminator	1400 m
Temperature	-20° C - +65° C
Battery	CR123A (2)
Battery Life (mode dependent)	> 3 hours
Material	Aircraft Aluminum
Weight (with battery)	12 oz
Dimensions	4.5(L) x 3.4(W) x 2.1(H) in.
Waterproof	Submersion to 20 m
Mount	QD HT Mount
Windage and Elevation Adjustment	Yes
Activation Switch	Integrated Push Button
Remote Cable Pressure Pad	Yes
Warranty	2-Year
Special Features	Dual Remote Cable Ports
